SR1000 truck Refrigeration Units

Snewang SR1000 is an front split installation, which is suitable for traditional fuel heavy truck with a volume of 38m³-45m³, and the temperature control range is -18℃~+15℃.

Snewang truck refrigeration unit SR1000 is specially designed for traditional oil-fired refrigerated truck, which suitable for box volumes of 38-45m³, with a temperature range of -18℃~+15℃. The product has the advantages of strong refrigeration capacity, lightweight design, accurate temperature control and double-drive power for the unit. Reliable compressor, control valves, and electrical components increase the service life and stability of the unit.


Technical parameter

modelSR1000
Applicable volume38-45m³
Temperature range-18~+15
Refrigerating capacity0/+3010100
-18/+305700
RefrigerantR404
Refrigerant charge3.6kg
CondenserSize mm (length * width * height)1915*354*337
Weight55
Condensing fanQuantity4
Total air volume4800m³/h
EvaporatorSize mm (length * width * height)1404*623*326
Weight43.1
Evaporation fanQuantity3
Total air volume5400m³/h




Snewang Small Van Refrigeration Units Product Features

  1. The evaporator adopts aluminum alloy shell, high strength and corrosion resistance;
  2. The condenser shell is made of ABS thermoplastic environmentally-friendly material, environmentally-friendly and recyclable, bright appearance and good performance.
  3. The heat exchanger’s large volume and High-volume air supply, ensure efficient heat exchange capacity and sufficient cold delivery;
  4. The controller utilizes light-touch temperature and airflow adjustment, has a wide range of temperature adjustment (-25°C to +30°C);
  5. Industry-unique double sealing technology, system leakage is less than 3 g/year, long-term reliable operation without leakage;
  6. The electric control system has multi-channel detection, multiple protection to ensure that the control system is safe and reliable;
  7. U.S. AMP/Delphi waterproof connector, pulling force greater than 180N/M, sealing waterproof, eliminate poor contact, thicker wire, high temperature does not heat;
  8. Danish Danfoss (DANFOSS) control valve, precise control, low failure rate;
  9. After-sales service quick response, more than 380 service outlets nationwide for easy maintenance.

Application Cases of Truck Refrigeration Unit

Brand

SNEWANG

Model

SR1000, SR1100
